Details
FX Sport 6 is the lightest and fastest fitness bike in the lineup. It has every performance feature of a high-end road bike, with the added benefit of a flat handlebar for additional comfort and control. A lightweight 400 Series OCLV Carbon frame, a high-quality Shimano drivetrain, and Bontrager carbon wheels make it the best choice for serious fitness riders with serious goals.
– A fitness bike that’s every bit as fast and capable as the race bikes found in our road lineup
– The 1x drivetrain delivers a wide range of gearing with the simplicity of a single shifter
– The cables are routed internally, which protects them from the elements and adds to the bike’s sleek look
– It’s easy to accessorize with fenders, lights, and more!
Geometry
| Size | X-Small | Small | Medium | Large | X-Large |
|---|---|---|---|---|---|
| A — Seat tube (cm) | 35.6 | 40.6 | 45.7 | 50.8 | 55.9 |
| B — Seat tube angle | 75.0° | 74.5° | 74.0° | 73.5° | 72.5° |
| C — Head tube length (cm) | 11.5 | 14 | 16.5 | 19 | 21.5 |
| D — Head angle | 70.0° | 70.5° | 71.0° | 71.5° | 72.5° |
| E — Effective top tube (cm) | 52.8 | 54.3 | 56.3 | 58.3 | 61.3 |
| F — Bottom bracket height (cm) | 28.5 | 28.5 | 28.5 | 28.5 | 28.5 |
| G — Bottom bracket drop (cm) | 6.5 | 6.5 | 6.5 | 6.5 | 6.5 |
| H — Chainstay length (cm) | 44.2 | 44.2 | 44.2 | 44.2 | 44.2 |
| I — Offset (cm) | 5 | 5 | 5 | 5 | 5 |
| J — Trail (cm) | 7.4 | 7.1 | 6.8 | 6.4 | 5.8 |
| K — Wheelbase (cm) | 104.7 | 105.4 | 106.5 | 107.5 | 108.2 |
| L — Standover (cm) | 70.8 | 75.1 | 78.7 | 81.2 | 84.8 |
| M — Frame reach (cm) | 38.3 | 38.5 | 39.3 | 40 | 41 |
| N — Frame stack (cm) | 54.3 | 56.8 | 59.4 | 62 | 64.8 |
Sizing
| Size | Height (inches) | Height (cm) |
|---|---|---|
| X-Small | 4’10” – 5’1” | 147 – 155cm |
| Small | 5’1” – 5’5” | 155 – 165cm |
| Medium | 5’5” – 5’9″ | 165 – 175cm |
| Large | 5’9” – 6’1″ | 175 – 186cm |
| X-Large | 6’1” – 6’6″ | 187 – 197cm |
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Deep Smoke / Small | 601842667231 | 5267863 | FXS24983277E |
| Deep Smoke / Medium | 601842667224 | 5267864 | FXS24906264E |
